Waygate Technologies Everest Mentor Visual iQ+ VideoProbe
Equipped with voice-activated commands enabling live video freeze-framing, dark boost increase, image saving and more.
Overview
Features
- Available as a basic Start, Enhance, or Pro package
- Voice control of device using any available audio input (internal microphone, USB audio, or Bluetooth)
- User storage:
- Start: 40gb
- Enhance: 80gb
- Pro: 160gb
- 6.5in active matrix XGA color LCD, daylight readable display
- Dual-band Wi-Fi and Bluetooth 4.0 enabled
- 212°F (100°C) max operating temp
- Rolling carry-on case or large work station model
- IP65, MIL-STD-810H, and MIL-STD-461G standards
Description
The Waygate Technologies Everest Mentor Visual iQ+ VideoProbe includes voice control that uses any audio input (internal microphone, USB audio, or Bluetooth). All audio processing is completed locally on the borescope and audio recordings are never stored or transmitted (unless unmuted video recording or audio annotation is happening at the time of the voice command session).
The Everest MVIQ+ also includes enhanced articulation of the sensor cable, with 360º All-Way tip articulation, menu access, and navigation.
The MVIQ+ comes with InspectionWorks, a secure and scalable cloud-based inspection platform that integrates every component of nondestructive testing (NDT), turning data into useful intelligence for faster and better decisions. Access the central cloud repository to enable the download of MDI/ADR/media to the device, and access ADR algorithms to analyze and increase processing efficiency.
Everest Mentor Visual iQ+ Start
The Start package is ideal for just-the-basics applications, and includes:
- Touch screen
- 40gb user storage
- Menu directed inspection
- Comparison measurement
- InspectionWorks Basic
- Far Field Audio
- 90-day analytics trial
- Over-the-air free software updates
Everest Mentor Visual iQ+ Enhance
The Enhance package is best for those just trying out analytics. It includes everything from the Start package, plus:
- Interchangeable probes
- 80gb user storage
- HD imaging
- Turning Tool 2.0
- 1-year analytics package (Blade Counter/Gas Power-assist)
Everest Mentor Visual iQ+ Pro
The Pro package is fully equipped for complex inspections. It includes everything from the Start and Enhance packages, plus:
- 160gb user storage
- 2-year analytics package (Blade Counter/Gas Power-assist)
- All POD measurement bundle options
- Future features such as measurement types and imaging options
