Overview

Features

  • 0.5 A to 2500 A AC range
  • 0.1A resolution
  • 3% ±5 digits accuracy
  • Record up to 65,000 readings
  • 3 1/2 LCD with backlight display
  • 25.4 cm (10 in) coil jaw opening
  • Operating temp: 50 to 122°F (-10 to 50°C)
  • CAT IV 600 V, CAT III 1000 V

Description

The Fluke FLK-CNX I3000 iFlex True-RMS AC Current Clamp Module that wirelessly relays measurements to the CNX 3000 Wireless Multimeter. The iFlex™ Wireless Current Module allows you to measure around awkward sized conductors and makes wire access easier.

Connect the CNX i3000 iFlex AC Wireless Current Module to your test point, and view the results up to 20 meters away on the CNX Wireless Multimeter. You'll save time, with less run-around, collecting multiple measurements. Use multiple modules for measurements on three-phase systems. Or use as a stand-alone measurement tool or combine with other CNX modules as a system for multiple measurements. From short distances, you can even view readings from modules through closed electrical panels. Plus, no more writing down data as the CNX i3000 Current Module captures up to 65,000 sets of time stamped min/max/avg readings, using the optional PC adapter. CNX wireless test tools also offer increased safety by letting you view readings in a separate location from the test point. Now you can take readings on moving machinery, with only the measurement module in harm's way.
