E+H Flowphant T DTT35 Flow Switch

Name: E+H Flowphant T DTT35 Flow Switch
Price: 497.97 USD
Availability: InStock

3-A approved design with minimal pressure loss. LCD display with rotational top section. Range of hygienic process connections available.

Starting at $497.97

View Company Reviews

Manufactured

By Endress+Hauser
Made in the USA

Includes

FREE Ground Shipping on orders of $1,000 or more
FREE Lifetime Tech Support

Availability

Manufacturer has some models in stock. View available part numbers.

Product Manual Product Specs

Features

Measuring principle: thermal
Nominal diameter: DN 25 to 1000 (1 to 40in)
Max measurement error: 2 to 10%
Max process pressure: 100bar (1740psi)
Measuring range: 0.03 to 3 m/s (0.1 to 9.84 ft/s)
Medium temperature range:
- -20 to 85°C (-4 to 185°F)
- CIP-able to 130°C / 266°F
Display: LED, LCD
Output(s):
- 1 x PNP switchable output
- 1 x 4 to 20mA analog output
IP66
3-A, EHEDG

The E+H Flowphant T DTT35 Flow switch measures relative mass flow rates of liquid mediums with virtually no pressure loss. The DTT35 can be configured with a second switch output or 4 to 20mA analog output for temperature monitoring or flow rates output as a percentage. The design includes 3-A and and EHEDG certification, with varied hygienic process connections for adaptable installation to numerous applications. Function checks and processing information happen onsite thanks to the digital LCD display. A 310 degree rotational top house section makes for ready display access in various installation positions.

The E+H Flowphant T DTT35 Flow Switch:

Cooling water circuit monitoring
Leak monitoring
Lubrication circuit monitoring
Filter monitoring

Spec Sheets

E+H Flowphant T DTT35 Flow switch Datasheet (1.1 MB)

Manuals

E+H Flowphant T DTT35 Flow switch Manual (1023 KB)

Manufacturer Stock

This stock is typically available to ship in 2 - 4 working days

Part Number	Price	Available
DTT35-A1A111DB2BAB Show Configuration	$497.97	2 in stock
DTT35-A3A111DL2BAB Show Configuration	$529.88	1 in stock

Interested in Other Part Numbers?

Other part numbers are available to order but are not currently in stock. Current availability for non-stock parts is "Usually ships in 2-3 weeks". Click here to select options
