Amprobe AMP-220 TRMS Clamp Meter

Full range of AC/DC current, AC/DC voltage, and frequency measurement functions for basic electrical troubleshooting.

Features

  • Measuring ranges:
    • Voltage up to 600 VAC/DC
    • AC/DC current up to 600A
    • Frequency 5.00 to 999.9 Hz
    • Resistance up to 60.00 kΩ
    • Capacitance up to 2500 µF
  • True-RMS
  • Low Pass Filter
  • Amp-Tip Functions
  • Non-contact voltage detection (NCV)
  • Audible continuity and diode test
  • CAT III 600V safety rated

What's in the Box

  • Test leads
  • Carrying case
  • Two AAA batteries
  • User Manual

The Amprobe AMP-220 TRMS Clamp Meter features a full range of AC/DC current, AC/DC voltage, and frequency measurement functions for basic electrical troubleshooting, the AMP-220 clamp meter with its large backlit display is an excellent amp clamp meter choice. Rated CAT III 600 V, the AMP-210 clamp meter offers True-RMS sensing, fast response processor, non-contact voltage detection, capacitance, resistance and continuity measurements to enhance efficiency and safety in today's complex electrical environments. The Amp-Tip function allows for precise measurement of current down to the tenth of an Amp, enabling accurate current measurement of both large and small diameter wires. A low pass filter allows measurement of current and voltage on variable frequency drives (motors with speed controlled by frequency).
