Overview

Features

  • 0.20% accuracy
  • 4-20mA, switch
  • 4:1 rangedown
  • Up to 360 psig (24.8bar) measurement range
  • Up to 257°F (125°C); 293°F(145°C) process temperature
  • Ceramic, PTFE, 316L SST Polished to Ra<16 µ-in (0.4µ-m)
  • 3-A, FDA, EC 1935, EC 2023, IP69K

Description

The Rosemount 326P Pressure Transmitter is specifically engineered for pressure and hydrostatic level applications in the food and beverage industry. A variety of industry standard process connections, hygienic certifications, a polished stainless steel housing, and the ability to withstand clean-in-place processes enable the transmitter to meet your process requirements while minimizing contamination risks and assuring product safety.

The Rosemount 326P Pressure Transmitter G1" process connection is compatible with full suite of hygienic process connection adapters and its compact form factor enables installation in applications with space constraints. The Rosemount 326P M12 electrical connector allows for simple installation and start-up while the Local Operator Interface (LOI) makes for simple, local commissioning on-site without the use of extra tools.
