E+H Prosonic FMU44 Ultrasonic Sensor

Name: E+H Prosonic FMU44 Ultrasonic Sensor
Price: 4583.03 USD
Availability: BackOrder

Designed for sophisticated level measurement in liquids and bulk solids for up to 20m.

Starting at $4,583.03

View Company Reviews

Manufactured

By Endress+Hauser
Made in the USA

Includes

FREE Ground Shipping
FREE Lifetime Tech Support

Availability

Usually ships in 2-3 weeks

Product Manual Product Specs

Features

Flange process connection
-40 to 176°F(-40 to 80°C) temp range
10 to 36psi (0.7 to 2.5bar) pressure range
Maximum measuring distance:
- Liquids 66ft (20m)
- Solids 33ft (10m)
Blocking distance: Liquids and Solids 1.9ft (0.5m)
International explosion protection certificates

The E+H Prosonic FMU44 Ultrasonic Sensor is suited for non-contact level measurement in fluids, pastes, coarse bulk material and flow measurement in open channels or at weirs. The two-wire or four-wire compact transmitter can be used in applications with storage tanks, agitators, on stockpiles and conveyor belts. The envelope curve can be shown on the on-site display for simple diagnosis. Linearization function (up to 32 points) for conversion of the measured value into any unit of length, volume or flow rate.
