Fuji Electric V6 Series FKG Gauge Pressure Transmitter

Name: Fuji Electric V6 Series FKG Gauge Pressure Transmitter
Price: 1470.36 USD
Availability: BackOrder

Measures liquid, gas or steam for gauge pressures up to 7,252 psi, universal HART communications protocol.

Starting at $1,470.36

Effective April 10th, 2025, Fuji has added a 10% surcharge to this product. The surcharge will appear as a separate line item on the order.

View Company Reviews

Manufactured

By Fuji Electric

Includes

FREE Ground Shipping
FREE Lifetime Tech Support

Availability

Usually ships in 6-8 weeks

Product Manual Product Specs

Features

Range 1 to 7,252 psi gauge (1 to 500 bar)
Up to ±0.04% accuracy
40ms response time
±0.1% of upper range limit stability
-40 to 212°F (-40 to 100°C) process temperature for silicone fill sensor
HART 7 communication protocol
Safety Integrity Level 2 or 3 according to IEC 61508 and IEC 61511 standards
Hazardous area approvals
IP66/IP67 and NEMA 4X
5-digit local display
Optional LCD display with 3 magnetic push buttons for contactless configuration

The Fuji Electric V6 Series FKG gauge pressure transmitter uses a unique micro-capacitive silicon sensor and state-of-the-art digital signal processing to provide exceptional accuracy and stability. The transmitter's silicon sensor assures this accuracy for all elevated or suppressed calibration ranges without additional adjustment. Using a silicon measurement diaphragm limits hysteresis and mechanical fatigue problems on the sensitive element, and provides the user with very high zero stability and long-term reliability.

The FKG V6 transmitter's advanced floating cell technology protects against temperature variations and overpressure, and substantially reduces the overall measurement error. The burnout current value can be adjusted in the ranges of 3.4 to 3.8 and 20.8 to 22.5 mA, and can be compliant with NAMUR NE43 recommendations. The transmitter's output signal can be linearized using up to 14 points.

The electronics unit, local indicators and electronics housing are interchangeable among all FCX-AIV V6 transmitters. Various options are available to address a wide range of process industry applications, including a full range of hazardous area approvals, a built-in RFI filter and lightning arrester, 5-digit local display with engineering units, stainless steel electronics housing, and a wide selection of wetted part materials. An optional local configurator with three magnetic switches allows the user to configure the transmitter without opening the indicator cover.
