SolaHD SDN-C RED Redundancy Module Power Supply

Name: SolaHD SDN-C RED Redundancy Module Power Supply
Price: 247.08 USD
Availability: InStock

True isolation and compact size to save panel space.

Starting at $247.08

View Company Reviews

Manufactured

By SolaHD

Includes

FREE Ground Shipping on orders of $1,000 or more
FREE Lifetime Tech Support

Availability

Manufacturer has some models in stock. View available part numbers.

Product Manual Product Specs

Features

12 to 24VDC
50/60Hz
Max. current:
- 10 to 40A (redundant)
- 20 to 80A (non-redundant)
-20 to 70°C operating temperature
Visual status indicator: (3) two-color LEDs
DIN TS35/7.5 or TS35/15 mounting
Extensive diagnostics
Load balancing support extends power supply life
Use in hazardous locations, with T4 temperature rating
Works with a wide variety of power supplies
Conformal coating option for particularly challenging environments available
Certifications:
- cULus
- cRUus
- CE
- ATEX
- IECEx
- ExEAC
- ABS
- DNV-GL
- RoHS

The SolaHD SDN-C RED Redundancy Module Power Supply continually monitors the condition of two power supplies connected to a single load. If one power supply fails, the RED module automatically changes over to the other power supply.

The MOSFET design for the RED modules generate less heat than traditional diode-based designs. Less heat translates to longer life of the components that are housed in the same enclosure as the RED module, and a more compact design of the RED module itself, saving on panel space.

Diagnostic LEDs assist in balancing the load between the two power supplies during normal operation, extending the life of both power supplies. Output status information can be easily provided to a PLC or other control equipment, using the RED module’s relay output contact.

Extensive certifications mean the RED modules are suitable internationally, for harsh industrial environments and even hazardous locations. The RED module works with SolaHD SDN-C and SDN-P Series power supplies, as well as most power supplies capable of parallel operation.

Applications

Hazardous locations
Process control
Critical production
Remote locations

Spec Sheets

SolaHD SDN-C RED Redundancy Module Power Supply datasheet (254 KB)

Manuals

SolaHD SDN-C RED Redundancy Module Power Supply manual (767 KB)

Manufacturer Stock

Part Number	Price	Available
SDN2X10REDXEPM Show Configuration	$273.08	10 in stock

Interested in Other Part Numbers?

Other part numbers are available to order but are not currently in stock. Current availability for non-stock parts is "Usually ships in 2-4 weeks". Click here to select options
